Evaporative Fresh Air Conditioning Heat Recovery Unit HVAC Energy Saving

Name: Evaporative Fresh Air Conditioning Heat Recovery Unit HVAC Energy Saving
Brand: GUANGZHOU JETEX-LLOYD'S MACHINERY LTD
SKU: HRDX
Availability: InStock

Product Details:

Place of Origin:	Guangzhou, Guangdong, China
Brand Name:	JETEX-LLOYD'S
Certification:	Utility Model Patent Certificate
Model Number:	HRDX

Detail Information

Place of Origin:

Guangzhou, Guangdong, China

Brand Name:

JETEX-LLOYD'S

Certification:

Utility Model Patent Certificate

Model Number:

HRDX

Air Volume:

3000m³/h-50000m³/h

Panel Material:

Double-layer Insulation Cotton Board, Color Steel Plate, Galvanized Steel Plate, Stainless Steel Plate

Function:

Efficient And Energy-saving

Name:

HVAC Heat Recovery Unit

Highlight:

High Light

Highlight:

Fresh Air Heat Recovery Unit HVAC

Air Conditioning Heat Recovery Unit HVAC

HVAC Heat Recovery Unit Energy Saving

Trading Information

Minimum Order Quantity:

One

Price:

negotiable

Packaging Details:

Specialized packaging film

Delivery Time:

25 work days

Payment Terms:

Bank transfer

Supply Ability:

500 units per month

Product Description

Evaporative Heat Recovery Air Conditioning Unit

The unit is specially designed for different fresh air areas. The air volume covers 3000-50000m³/h. It adopts exclusive heat recovery technology and is especially suitable for areas with large air volume and long transition seasons to achieve significant energy saving effects. The unit integrates refrigeration, heating, humidification, dehumidification and purification and sterilization functions, and supports precision and remote control.
The unit adopts three-stage heat recovery technology: high-efficiency two-way hot and wet filler full heat recovery, refrigerant heat pump direct expansion full heat recovery and condensate water replenishment technology. The full heat recovery efficiency is as high as more than 70%. The unique "airflow variable air channel" technology realizes multi-working mode operation, including cooling, cooling and dehumidification, heating heat recovery and non-refrigeration cooling functions, making the air conditioning system energy-saving by more than 35%.
Product advantages:
1. There is zero contact between indoor and outdoor air, no cross-contamination, and air quality is guaranteed.
2. Variable working conditions, one machine for multiple purposes.
3. High efficiency, energy saving, intelligent control.
4. Flexible installation to adapt to different project needs.
Low maintenance cost, long service life and high cost performance

Model No	HRDX
Air volume	3000m³/h-50000m³/h
Panel material	Double-layer insulation cotton board, color steel plate, galvanized steel plate, stainless steel plate
Cooling capacity	30KW-800KW
Product features	Efficient and energy-saving
Heating capacity	/
Humidification capacity	/
Motor power	0.5KW-55KW
Pressure	250Pa-500Pa
Power supply	380V/3PH/50HZ-415V/3PH/50HZ
Cooling water coil	4 Rows-8 Rows
size	Customizable

Evaporative Fresh Air Conditioning Heat Recovery Unit HVAC Energy Saving 0

Evaporative Fresh Air Conditioning Heat Recovery Unit HVAC Energy Saving 3
