Jetex Modular Rotary Dehumidifier Air Handling Unit Energy Saving

Jetex Modular Rotary Dehumidifier Air Handling Unit Energy Saving

modular rotary dehumidifier air conditioner

energy saving rotary dehumidifier

jetex rotary dehumidifier with warranty

Place of Origin:

Guangzhou, Guangdong, China

Brand Name:

JETEX

Certification:

ISO quality system certification,CRAA

Model Number:

DCW Series

Contact Us
Request A Quote
Product Details
Air Volume:
2000m³/h-100000m³/h
Function:
Cooling, Heating, Dehumidifying, Filtering, Purifying And Sterilizing(fuctional Sections Can Be Customized )
Panel Material:
Double-layer Insulation Cotton Board, Color Steel Panel , Galvanized Steel Panel , Stainless Steel Panel
Name:
Modular Rotary Dehumidifier,low Dew Point Dehumidifier
Highlight:

modular rotary dehumidifier air conditioner

,

energy saving rotary dehumidifier

,

jetex rotary dehumidifier with warranty

Payment & Shipping Terms
Minimum Order Quantity
One
Price
negotiable
Packaging Details
Specialized packaging film
Delivery Time
35 work days
Payment Terms
Western Union,MoneyGram,T/T
Supply Ability
1000 units per month
Product Description
Jetex Low Dew Point Dehumidifier,Rotary Wheel Desiccant Dehumidifier
Product Specifications
Attribute Value
Air volume 2000m³/h-100000m³/h
Function Cooling, heating, dehumidifying, filtering, purifying and sterilizing (functional sections can be customized)
Panel material Double skin, polyurethane foam insulation ,outside panel : color steel sheet , inside panel:galvanized steel sheet , stainless steel sheet panel(optional )
Name Rotary Desiccant Dehumidifier,low dew point dehumidifier
Product Description
1. Structure of the Rotary Dehumidifier:
  • Desiccant Wheel (Rotor): The core component is a large, porous wheel made from desiccant material (like silica gel or zeolite) that absorbs moisture from the air. The wheel is divided into two sections: the process air section and the reactivation air section.
  • Air Inlet and Outlet: Separate air channels for the process air (needing dehumidification) and reactivation air (used to regenerate the desiccant).
  • Blowers/Fans: Move air through the system, with separate fans for process air and reactivation air.
  • Heater: Typically used to warm reactivation air to regenerate the desiccant material by releasing absorbed moisture.
2. Process Air Dehumidification:
  • Air Intake: Moist air from the environment is drawn into the dehumidifier through the process air inlet.
  • Moisture Absorption: As air passes through the rotating desiccant wheel, moisture is absorbed, resulting in dry air discharge.
  • Continuous Operation: The wheel rotates slowly (8-12 revolutions per hour), allowing constant dehumidification as different portions contact incoming air.
Key Benefits
  • High degree of customization to meet unique project requirements
  • Easy modification or expansion as building needs change
  • Potential for significant energy savings
  • Improved indoor air quality
Jetex Modular Rotary Dehumidifier Air Handling Unit Energy Saving 0
Jetex Modular Rotary Dehumidifier Air Handling Unit Energy Saving 1
Jetex low low dew point dehumidifier technical parameters Jetex Modular Rotary Dehumidifier Air Handling Unit Energy Saving 2
Industrial Applications
  • Industry, Scientific Research, Electric Power Transportation
  • Lithium Battery Industry, Biotechnology Pharmaceutical Industry
  • Chemical, Daily Chemical Industry, Food Beverage Industry
  • Safety Glazing Material Industry, Tyre and Rubber Industry
  • Medical Instrument, Vegetables Frozen, Precise Instrument
  • Wood Goods, Shipbuilding Painting Industry, Various Storage Facilities
 Jetex Modular Rotary Dehumidifier Air Handling Unit Energy Saving 3

Company profile

  Guangzhou Jetex-Lloyd's Machinery Ltd.,founded in 1995, is a professional manufacturer of indoor air treatment equipment .For 30 years,the company has maintained a stable development, focusing on producing high quality efficient product .It has been widely recognized by professionals from all walks of life and enjoy high reputation,making it a trusted leader in the air conditioning treatment market. As an industry-recognized expert, the company provides quality products and services for various sectors, including electronic ,semiconductor,commercial building ,biological medicine.precision machinery ,tobacco,environmental protection, dust collection, scientific research and teaching ,food processing and other industries,earning the trust of users .


Jetex Modular Rotary Dehumidifier Air Handling Unit Energy Saving 4


JETEX  Low Dew Point Dehumidifier Application Cases

Amway (China) Co., Ltd.

Winston Battery Limited.

Foxconn Technology Group.

Guangzhou Qiaoguang Pharmaceutical Factory.

BYD Company Limited .

LI-ION Technologies Limited(Russian Federation).etc



Jetex Modular Rotary Dehumidifier Air Handling Unit Energy Saving 5

Our Cetificates


 Jetex Modular Rotary Dehumidifier Air Handling Unit Energy Saving 6


Exhibitions Jetex Modular Rotary Dehumidifier Air Handling Unit Energy Saving 7


Production Lead Time
Quantity (units) 1 - 1 > 1
Lead time (days) 35 To be negotiated
Customization Options
  • Customized logo (Minimum order: 10 units)
  • Customized packaging (Minimum order: 10 units)
  • Project solution (Minimum order: 3 units)
