JETEX Air Handlers For The Semiconductor Industry

MOQ: One
Price: negotiable
Standard Packaging: Specialized packaging film
Delivery Period: According to your order
Payment Method: Western Union,MoneyGram,T/T
Supply Capacity: 1000 units per month
Detail Information
Product Description
Detail Information
Place of Origin
Guangzhou, Guangdong, China
Brand Name
JETEX
Certification
ISO quality system certification/CRAA
Model Number
AHS series
Air Volume:
2000m³/h-300000m³/h
Function:
Cooling, Heating, Humidifying, Dehumidifying, Filtering, Purifying And Sterilizing
Panel Material:
Double-layer Insulation , Color Steel Sheet , Galvanized Steel Sheet, Stainless Steel Sheet(Optional)l
Name:
Modular Air Handling Units
Fan:
Volute/Non-volute Fan /EC Fan Options Available
Cooling Capacity:
12kw-5000kw
Insulated Material:
Polyurethane Foam,thickness(50mm)
Highlight:

semiconductor industry air handlers

,

JETEX air handling units

,

industrial air conditioner for semiconductors

Product Description
JETEX Air Handlers For The Semiconductor Industry Air Conditioner
Product Specifications
Attribute Value
Air volume 2000m³/h-300000m³/h
Function Cooling, heating, humidifying, dehumidifying, filtering, purifying and sterilizing
Panel material Double-layer insulation, color steel sheet, galvanized steel sheet, stainless steel sheet (Optional)
Name Modular Air Handling Units
Fan Volute/Non-volute Fan /EC fan options available
Cooling capacity 12kw-5000kw
Insulated material Polyurethane foam, thickness (50mm)
Advanced Functions of AHUs in Semiconductor Fabs
  • Multi-Stage Filtration: HEPA/ULPA filters achieve ISO Class 1-5 cleanroom standards, removing particles as small as 0.1-0.3 microns. Chemical filtration (e.g., activated carbon) may be added to absorb airborne molecular contaminants (AMCs).
  • Pressure Cascade Control: Maintains positive/negative pressure gradients between cleanroom zones to prevent cross-contamination, critical in photolithography and etching areas.
  • Redundancy and Reliability: N+1 redundancy ensures uninterrupted operation. Backup systems (dual fans, emergency power) are critical for 24/7 fabs.
  • Energy Efficiency Innovations: Includes Variable Frequency Drives (VFDs), heat recovery systems, AI/ML-based control, and EC fans to optimize energy use.
Jetex AHU Technical Details
Model NO. Jetex AHS series
Type Modular air Handling Unit/air handler
Frame structure Aluminum alloy
Air pipe Material Galvanized
Mounting Vertical or ceiling mounted
Operating Voltage 380/400 VAC
Air volume 2000~100000 m³/h
Lifetime About 15 years
Fan Type EC fan /belt drive volute fan
Panel sheet material Colored steel sheet and galvanized sheet 0.5mm
Insulated polyurethane foam thickness 50mm
Functions Cooling, heating, humidifying, dehumidifying, filtering, purifying and sterilizing, ventilation etc.
Power supply 380V/50HZ/3P
Cooling capacity 12kw-5000kw
Numbers of row 2 rows/6 rows /8 rows
Frequently Asked Questions
Q1: Can you manufacture non-standard machine?
A1: Yes, our factory has 30 years experience in manufacturing. You just need to provide us with technical parameters, and our engineers will develop a solution for you.
Q2: How about the quality of your product?
A2: Our products are manufactured strictly according to national and international standards. We have CE, CRAA certification and perform tests on every product before shipment.
Q3: How to choose a suitable machine?
A3: Please provide us with your specifications and building drawing, and our professional technical engineers will assist you.
