Air Conditioning Solutions Vendor Air Handling Unit For Commercial Buildings
  • name
  • name

Air Conditioning Solutions Vendor Air Handling Unit For Commercial Buildings

MOQ: One
Price: negotiable
Standard Packaging: Specialized packaging film
Delivery Period: According to your order
Payment Method: Western Union,MoneyGram,T/T
Supply Capacity: 1000 units per month
Detail Information
Product Description
Detail Information
Place of Origin
Guangzhou, Guangdong, China
Brand Name
JETEX
Certification
ISO quality system certification/CRAA
Model Number
AHU
Air Volume:
2000m³/h-300000m³/h
Function:
Cooling, Heating, Humidifying, Dehumidifying, Filtering, Purifying And Sterilizing
Panel Material:
Double-layer Insulation , Color Steel Plate, Galvanized Steel Plate, Stainless Steel Plate(Optional)l
Name:
Modular Air Handling Units
Fan:
Volute/Non-volute Fan /EC Fan Options Available
Highlight:

commercial air handling unit

,

HVAC air handling unit

Product Description
Air Conditioning Solutions Vendor Air Handling Unit For Commercial Buildings
Product Overview

An Air Handling Unit (AHU) is a core component of a commercial HVAC system, responsible for circulating, filtering, heating, and cooling air within a building. It acts as the "lungs" of the building, drawing in outside air, treating it, and distributing it through ductwork to maintain a comfortable and healthy indoor environment.

Key Features
  • Air volume range: 2000m³/h-300000m³/h
  • Multiple functions: Cooling, heating, humidifying, dehumidifying, filtering, purifying and sterilizing
  • Panel material options: Double-layer insulation, color steel plate, galvanized steel plate, stainless steel plate
  • Fan options: Volute/Non-volute Fan /EC fan available
  • Modular design for flexible configuration
Technical Specifications
Attribute Value
Model NO. Jetex AHS series
Type Modular air Handling Unit/air handler
Panel sheet material Colored steel sheet and galvanized sheet 0.5mm
Frame structure Aluminum alloy
Insulated polyurethane foam thickness 50mm
Air pipe Material Galvanized
Functions Cooling, heating, humidifying, dehumidifying, filtering, purifying and sterilizing, ventilation etc.
Mounting Vertical or ceiling mounted
Power supply 380V/50HZ/3P
Operating Voltage 380/400 VAC
Cooling capacity 12kw-5000kw
Air volume 2000~100000 m³/h
Numbers of row 2 rows/6 rows /8 rows
Lifetime About 15 years
Filter type Bag Filter, Primary Filter, Activated Carbon Filter, HEPA Filter, etc
Benefits
  • Improved Indoor Air Quality: Filters and circulates air to remove pollutants and maintain a healthy environment
  • Comfortable Temperatures: Ensures consistent and comfortable temperatures throughout the building
  • Energy Efficiency: Can incorporate energy-saving features like heat recovery to reduce consumption and costs
  • Customizable: Tailored to specific building needs including size, capacity, and specialized features
Custom Solutions

We provide comprehensive constant temperature and humidity air conditioning solutions tailored to your specific requirements. Contact our technical team for a fully developed solution to your air handling needs.

Air Conditioning Solutions Vendor Air Handling Unit For Commercial Buildings 0
Frequently Asked Questions
Q: How to get the air solutions from your company?
A: Contact us and send the detail requirements and technical specifications. Our team will develop a customized solution for you.
